Regular Horizontal Electrophoresis Systems

Regular Horizontal Electrophoresis Systems

Junior Horizontal Immersed Gel Electrophoresis Unit

    Specifications
  • Make : ORANGE
  • Model : Standard- Junior Horizontal
  • Dimension : 14.5cm(L)x6.5cm(B)x5.5cm(H)
  • Number of Samples : 5
  • Buffer Volume : 150ml
  • Number of casting Tray (W x L): 7x4cm (1 No.)
  • Number of Combs: 5-wells 1.5mm thickness comb (Well Width-5mm, Interspace-3mm) (2 Nos.)
  • 4-wells 1.5mm thickness comb (Well Width-6mm, Interspace-4mm) (1 No.)
  • Connecting Cord : Red and Black (Each One)
  • No. of Platinum electrodes : Positive and Negative (Each One)
  • Buffer Chamber with Safety Lid : 1 No.
  • Gel Caster : Optional* (Extra Cost)
  • Instruction Manual
  • Warranty card
Ordering Information
Cat. No Product Price
HJS0005 Junior Horizontal Immersed Gel Electrophoresis Unit Rs.6540.00

Mini Horizontal Immersed Gel Electrophoresis Unit

    Specifications
  • Make : ORANGE
  • Model: Standard-Mini Horizontal
  • Dimension: 18.5cm(L)x9.5cm(B)x7cm(H)
  • Number of Samples: 8
  • Buffer Volume: 300ml
  • Number of casting Tray (W x L): 7x5cm,10x7cm(1 No.Each)
  • Number of Combs: 8-wells 1.5mm thickness comb (Well Width-5mm, Interspace-3mm) (2 Nos.)
  • 3-wells 1.5mm thickness comb (Well Width-18mm, Interspace-4mm) (1 No.)
  • Connecting Cord: Red and Black (Each One)
  • No. of Platinum electrodes: Positive and Negative (Each One)
  • Buffer Chamber with Safety Lid: 1 No.
  • Gel Caster: Optional* (Extra Cost)
  • Instruction Manual
  • Warranty card
Ordering Information
Cat. No Product Price
HMS0008 Mini Horizontal Immersed Gel Electrophoresis Unit Rs.9350.00

Midi Horizontal Immersed Gel Electrophoresis Unit

    Specifications
  • Make : ORANGE
  • Model: Standard-Midi Horizontal
  • Dimension: 25.5cm(L)x15.5cm(B)x7cm(H)
  • Number of Samples: Up to 36
  • Buffer Volume: 450ml
  • Number of casting Tray (W x L) : 7x5cm,13x6cm,13x10cm (1 No. Each)
  • Number of Combs: 8-wells 1.5mm thickness comb (Well Width-5mm, Interspace-3mm) (1 No.)
  • 3-wells 1.5mm thickness comb (Well Width-18mm, Interspace-4mm) (1 No.)
  • 13-wells 1.5mm thickness comb (Well Width-5mm, Interspace-5mm) (2 Nos.)
  • 18-wells 1.5mm thickness comb (Well Width-4mm, Interspace-3mm) (2 Nos.)
  • Connecting Cord: Red and Black (Each One)
  • No. of Platinum electrodes: Positive and Negative (Each One)
  • Buffer Chamber with Safety Lid: 1 No.
  • Gel Caster: Optional* (Extra Cost)
  • Instruction Manual
  • Warranty card
Ordering Information
Cat. No Product Price
HDS0036 Midi Horizontal Immersed Gel Electrophoresis Unit Rs.16740.00

Maxi Horizontal Immersed Gel Electrophoresis Unit

    Specifications
  • Make : ORANGE
  • Model: Standard-Maxi Horizontal
  • Dimension: 25cms(L)x23cms(B)x7cms(H)
  • Number of Samples: Up to 60
  • Buffer Volume: 750ml
  • Number of casting Tray (W x L) : 20x15cm,20x20cm (1 No. Each)
  • Number of Combs: 26-wells 1.5mm thickness comb (Well Width-4mm,Interspace-3mm) (2 Nos.)
    30-wells 1.5mm thickness comb (Well Width-3mm,Interspace-3mm) (1 No.)
  • Connecting Cord: Red and Black (Each One)
  • No. of Platinum electrodes: Positive and Negative (Each One)
  • Buffer Chamber with Safety Lid: 1 No.
  • Gel Caster: Optional* (Extra Cost)
  • Instruction Manual
  • Warranty card
Ordering Information
Cat. No Product Price
HXS0060 Maxi Horizontal Immersed Gel Electrophoresis Unit Rs.24400.00

Maxi Horizontal Immersed Gel Electrophoresis with Water Circulation Unit

    Specifications
  • Make : ORANGE
  • Model: Standard-Maxi Horizontal
  • Dimension: 45cms(L)x25cms(B)x10cms(H)
  • Number of Samples: Up to 60
  • Buffer Volume: 750ml
  • Number of casting Tray (W x L): 20x15cm,20x20cm (1 No. Each)
  • Number of Combs: 26-wells 1.5mm thickness comb (Well Width-4mm,Interspace-3mm) (2 Nos.)
  • 30-wells 1.5mm thickness comb (Well Width-3mm, Interspace-3mm) (2 Nos.)
  • Connecting Cord: Red and Black (Each One)
  • No. of Platinum electrodes: Positive and Negative (Each One)
  • Buffer Chamber with Safety Lid: 1 No.
  • Water Circulation Port: Provided
  • Gel Caster: Optional* (Extra Cost)
  • Instruction Manual
  • Warranty card
Ordering Information
Cat. No Product Price
HWS0061 Maxi Horizontal Immersed Gel Electrophoresis with Water Circulation Unit Rs.26800.00

ACE Series Mini Horizontal Immersed Gel Electrophoresis Unit

    Specifications
  • Make : ORANGE
  • Model: ACE Series-Mini Horizontal
  • Dimension: 13cm(L)x24cm(B) x6.5cm(H)
  • Number of Samples: 15
  • Buffer Volume: 320ml
  • Number of casting Tray (W x L) :7x5cm,10x7cm(1 No.Each)
  • Number of Combs: Multichannel Pipette Compatible Combs
  • Height Adjustable Combs
  • 15-wells 1.5mm thickness comb (Well Width-3mm, Interspace-1.5mm) (1 No.)
  • 8-wells 1.5mm thickness comb (Well Width-5mm, Interspace-3mm) (1 No.)
  • 3-wells 1.5mm thickness comb (Well Width-18mm, Interspace-4mm) (1 No.)
  • Handle: Provided in the Unit
  • Connecting Cord: Red and Black (Each One)
  • No. of Platinum electrodes: Positive and Negative (Each One)
  • Buffer Chamber with Safety Lid: 1 No.
  • Gel Caster: 1 No.
  • Instruction Manual
  • Warranty card
Ordering Information
Cat. No Product Price
HMA0015 ACE Series Mini Horizontal Immersed Gel Electrophoresis Unit Rs.19800.00

ACE Series Mini Super Horizontal Immersed Gel Electrophoresis Unit

    Specifications
  • Make : ORANGE
  • Model: ACE Series-Mini Super Horizontal
  • Dimension: 16.5cm(L)x23cm(B)x6.5cm(H)
  • Number of Samples: 23
  • Buffer Volume: 400ml
  • Number of casting Tray (W x L) :7x5cm,10x11.5cm (1 No.Each)
  • Number of Combs: Multichannel Pipette Compatible Combs
  • Height Adjustable Combs
  • 23-wells 1.5mm thickness comb (Well Width-3mm, Interspace-1.5mm) (1 No.)
  • 8-wells 1.5mm thickness comb (Well Width-5mm, Interspace-3mm) (1 No.)
  • 3-wells 1.5mm thickness comb (Well Width-18mm, Interspace-4mm) (1 No.)
  • Handle: Provided in the Unit
  • Connecting Cord: Red and Black (Each One)
  • No. of Platinum electrodes: Positive and Negative (Each One)
  • Buffer Chamber with Safety Lid: 1 No.
  • Gel Caster: 1 No.
  • Instruction Manual
  • Warranty card
Ordering Information
Cat. No Product Price
HSA0023 ACE Series Mini Super Horizontal Immersed Gel Electrophoresis Unit Rs.24700.00

ACE Series Midi Horizontal Immersed Gel Electrophoresis Unit

    Specifications
  • Make : ORANGE
  • Model: ACE Series-Midi Horizontal
  • Dimension: 19.5cm(L)x28.5cm(B)x6.5cm(H)
  • Number of Samples: 52
  • Buffer Volume: 600ml
  • Number of casting Tray (W x L) :7x5cm,13x6cm,13x10cm (1 No.Each)
  • Number of Combs: Multichannel Pipette Compatible Combs
  • Height Adjustable Combs
  • 26-wells 1.5mm thickness comb (Well Width-3mm, Interspace-1.5mm) (2 Nos.)
  • 13-wells 1.5mm thickness comb (Well Width-5mm, Interspace-5mm) (2 Nos.)
  • 18-wells 1.5mm thickness comb (Well Width-4mm, Interspace-3mm) (2 Nos.)
  • 8-wells 1.5mm thickness comb (Well Width-5mm, Interspace-3mm) (1 No.)
  • 3-wells 1.5mm thickness comb (Well Width-18mm, Interspace-4mm) (1 No.)
  • Handle : Provided in the Unit
  • Connecting Cord: Red and Black (Each One)
  • No. of Platinum electrodes: Positive and Negative (Each One)
  • Buffer Chamber with Safety Lid: 1 No.
  • Gel Caster: 1 No.
  • Instruction Manual
  • Warranty card
Ordering Information
Cat. No Product Price
HDA0052 ACE Series Midi Horizontal Immersed Gel Electrophoresis Unit Rs.30800.00

ACE Series Midi Super Horizontal Immersed Gel Electrophoresis Unit

    Specifications
  • Make : ORANGE
  • Model: ACE Series-Midi Super Horizontal
  • Dimension: 21.5cm(L)x33.5cm(B)x7cm(H)
  • Number of Samples: 86
  • Buffer Volume: 1200ml
  • Number of casting Tray (W x L) : 20x10cm,20x20cm (1 No.Each) with Two slots
  • Number of Combs: Multichannel Pipette Compatible Combs
  • Height Adjustable Combs
  • 43-wells 1.5mm thickness comb (Well Width-3mm, Interspace-1.5mm) (2 Nos.)
  • 30-wells 1.5mm thickness comb (Well Width-3mm, Interspace-3mm) (2 Nos.)
  • 26-wells 1.5mm thickness comb (Well Width-4mm, Interspace-3mm) (2 Nos.)
  • Handle: Provided in the Unit
  • Connecting Cord: Red and Black (Each One)
  • No. of Platinum electrodes: Positive and Negative (Each One)
  • Buffer Chamber with Safety Lid: 1 No.
  • Gel Caster: 1 No.
  • Instruction Manual
  • Warranty card
Ordering Information
Cat. No Product Price
HSA0086 ACE Series Midi Super Horizontal Immersed Gel Electrophoresis Unit Rs.42400.00

ACE Series Maxi Horizontal Immersed Gel Electrophoresis Unit

    Specifications
  • Make : ORANGE
  • Model: ACE Series-Maxi Horizontal
  • Cat. No : HXA0162
  • Dimension: 33cm(L)x56cm(B)x9cm(H)
  • Number of Samples: 162
  • Buffer Volume: 2200ml
  • Number of casting Tray (W x L) : 25x30cm (1 No.) with Three Slots
  • Number of Combs: Multichannel Pipette Compatible Combs
  • Height Adjustable Combs
  • 54-wells 1.5mm thickness comb (Well Width-3mm, Interspace-1.5mm) (2 Nos.)
  • 35-wells 1.5mm thickness comb (Well Width-4mm, Interspace-3mm) (2 Nos.)
  • 40-wells 1.5mm thickness comb (Well Width-3mm, Interspace-3mm) (2 Nos.)
  • Handle: Provided in the Unit
  • Connecting Cord: Red and Black (Each One)
  • No. of Platinum electrodes: Positive and Negative (Each One)
  • Buffer Chamber with Safety Lid: 1 No.
  • Gel Caster: 1 No.
  • Instruction Manual
  • Warranty card
Ordering Information
Cat. No Product Price
HXA0162 ACE Series Maxi Horizontal Immersed Gel Electrophoresis Unit Rs.56150.00
